| Model No. | RD40F10030C7-WT | |
| AC Input | Input Voltage | Rated voltage 380VAC, 3W+PE, operating voltage range 270-490VAC |
| Input Frequency | 50/60Hz±10% | |
| Input Power Factor | ≥0.99 | |
| Input Overvoltage Protection | 490±10VAC | |
| Input Undervoltage Protection | 270±10VAC | |
| DC Output | Rated Output Power | 40KW |
| Output Voltage Range | 50-1000VDC | |
| Output Current Range | 0.5-134A | |
| Output Constant Power Range | 300-500VDC,600-1000VDC | |
| Peak Efficiency | ≥96% | |
| Soft Start Time | 3-8s | |
| Short Circuit Protection | Self-rollback protection | |
| Voltage Regulation Accuracy | ≤±0.5% | |
| THD | ≤5% | |
| Current Regulation Accuracy | ≤±1% | |
| Current Sharing Imbalance | ≤±5% | |
| Operating Environment | Working Tempurature | -40℃-75℃ |
| Relative Humidity | ≤95% no condensation | |
| Altitude | ≤2000m，derating above 2000m | |
| Product Features | Cooling Method | Fan cooling |
| Standby Power Consumption | ＜10W | |
| Communication Protocol | CAN | |
| Address Setting | Digital screen display,button operation | |
| Dimension | 437.5mm×300mm×84mm(D×W×H） | |
| Weight | ≤16kg | |
| MTBF | 500000 hours | |
