24V 1.2Ah High energy density and high reliability Valve regulated lead acid AGM technology UPS Battery High Performance Sealed Lead Acid Battery

Brand: Rader
Product origin: china
Delivery time: within 20 days
Supply capacity: 200 thousand per month

1. Valve regulated lead acid AGM technology
2. High energy density and high reliability

Product Description:

24V 1.2Ah UPS Battery High Performance Sealed Lead Acid Battery

Specifications

Nominal Voltage			24V
Capacity (25C)	20HR(21.0V)		1.2Ah
	10HR(21.0V)		1. 1Ah
	1HR(19.2V)		0.78Ah
Dimension	Length		194±1mm (7.64inch)
	Width		43±1mm (1.69inch)
	Height		52±1mm (2.05inch)
	Total Height		58±1mm (2.28inch)
Approx. Weight			1.1kg (2.42lbs)±5%
Terminal type			F1
Internal resistance (Fully charged, 25C)			Approx. 180mQ
Capacity affected by temperature (20HR)		40C	102%
		25C	100%
		0C	85%
		- 15C	65%
Self-discharge (25C)		3 month	Remaining Capacity: 91%
		6 month	Remaining Capacity: 82%
		12 month	Remaining Capacity: 65%
Nominal operating temperature			25C±3C(77℉±5℉)
Operatingtemperature range		Discharge	- 15C~50C(5℉~122℉)
		Charge	- 10C~50C(14℉~122℉)
		Storage	-20C~50C(-4℉~122℉)
Float charging voltage(25C)			27.2to 27.6V Temperature compensation: -36mV/C
Cyclic charging voltage(25C)			29.0to 30.0V Temperature compensation: -60mV/C
Maximum charging current			0.36A
Maximum discharge current			18A(5 sec.)
Designed floating life(20C)			5years
