Brand: Rader Product origin: china Delivery time: within 20 days Supply capacity100 thousand per month EverExceed Modular Range Valve Regulated Lead Acid (V.R.L.A.) batteries are designed for the long standby back-up power requirements of wireless/PCS telecommunications, MTSO's, central offices, utilities, and switchgear and control applications. EverExceed advanced AGM absorbed electrolyte technology ensures reliable performance, safety, outstanding battery life and value. Battery has a d
Technical features:
• Virgin Pure Lead Tin and thick positive plate technology design - 15 years design life @ 20˚C(68˚F);
• Valve regulated lead acid battery (VRLA);
• Optimized high-compression Absorbed Glass Mat (AGM) materials significantly enhance performance, greater than 99% recombination efficiency;
• Advanced triple stage unique terminal sealing design to ensure leak free operation;
• Operates at a low internal pressure;
• Heavy duty M6/M8 copper plated terminals provide maximum performance and easy installation, reduce maintenance and increase safety;
• Advanced lead tin low-calcium alloy, reduces grid corrosion and promotes long battery life;
• Designed to withstand extreme temperature degrees and performance without degradation;
• Over-sized, through the partition inter-cell welds provide low resistance connections.
• Multi-cell design for ease of installation and maintenance;
• Horizontal or vertical operation.
• Fixed Orifice Plate Pasting technology applying active materials on both sides of the grid for consistent performance.
Specifications
Nominal Voltage | 12 V | ||
Capacity (25C) | 10HR(10.8V) | 100Ah | |
3HR(10.5V) | 80Ah | ||
1HR(9.60V) | 64. 1Ah | ||
Dimension | Length | 330±2mm (12.99inch) | |
Width | 171±2mm (6.73inch) | ||
Height | 214±2mm (8.43inch) | ||
Total Height | 220±2mm (8.66inch) | ||
Approx. Weight | 30.3kg (66. 1lbs)±4% | ||
Terminal type | F14 | ||
Internal resistance (Fully charged, 25C) | Approx. 4.5mQ | ||
Capacity affected by temperature (10HR) | 40C | 102% | |
25C | 100% | ||
0C | 85% | ||
- 15C | 65% | ||
Self-discharge (25C) | 3 month | Remaining Capacity: 91% | |
6 month | Remaining Capacity: 82% | ||
12 month | Remaining Capacity: 65% | ||
Nominal operating temperature | 25C±3C(77℉±5℉) | ||
Operatingtemperature range | Discharge | - 15C~50C(5℉~122℉) | |
Charge | - 10C~50C(14℉~122℉) | ||
Storage | -20C~50C(-4℉~122℉) | ||
Float charging voltage(25C) | 13.50to 13.80 | ||
