Built-in intelligent BMS Long Life Cycles Phosphate LiFePO4 12V Solar Power Lithium Battery

Brand: Rader
Product origin:china
Delivery time: within 20 days

Supply capacity: 200 thousand per month

1. Short circuit test, no explosion, no fire
2. Heating test, no explosion, no fire
3. High safety:Over-charging test,no explosion,no fire,over-current,short circuit

Product Description:

12.8V 38Ah Lithium Iron Phosphate (Lifepo4) Battery

Model:RD-12-38-SA



Product Features

Safest LiFePo4: cells for safe use no fire no explosion

Long Life Cycles: >2000 cycles@0.2C,Charge/Discharge at 100%DOD

Powerful Energy: Quick charging,high quality and high discharge rate lithium battery cells providing more energy.

Light Weight: about 40%~50%of the weight of SLA battery

Built-in intelligent BMS: Over Charge /Discharge voltage and current protection, Short circuit protection ,Over temperature protection.


 Product Description


Electrical

Characteristics

Technology

Lithium Iron Phosphate

Nominal Voltage

12.8V

Nominal Capacity

38Ah± 5%@0.2C

Energy

0.486KWh

Cycle Life

100%Depth of Discharge ~2000cycles

Internal Resistance

20mΩ





Charge

Charge mode

CC&CV(0.2C Constant current &14.6V Constant voltage@0.02C)

Max.Charge Voltage

14.6V

Standard Charge Current

7.6A

Max.Charge Current

19A



Discharge

Discharge Cut-oVoltage

10V

Standard        Discharge Current

19A

Max.Continuous Discharge Current

38A

Operating

Condition

Storage Temperature

0℃ to 45℃(32to113)

Humidity

60±25%

Charge Temperature

0to 45℃(32to113)

DischargeTemperature

-20℃to 45℃(32to113)





Structure

Water Dust Resistance

IP65

Terminal

M6

Case and Cover

ABS

Dimension (L*W*H)

197*165*175mm

Weight

Approx  4.2Kg


Advantages

1. While thickness is changed,we can keep the length and width the same.

2. More flexible,size and capacity can  be customized

3. Low-self discharge rate
